Platinum AC/DC

Description

• • Superior quality aluminum alloy construction.
  • Energy efficient Electrical Steel Sheet and 99.9% Pure Copper Wire.
  • “E” grade varnish insulation to protect from electric shock and voltage fluctuation.
  • Aerodynamically designed blades for maximum air delivery.
  • High quality paint for superior finishing.
  • Packed in strong corrugated cartons with protective thermopore.

  General Specifications

  Type	Blades	Sweep	Warranty
  BLDC Hybrid	3	1400mm	Yes



  Technical Specifications Inverter

  MODE TYPE	AC MODE	DC MODE
  Rated Mode	230 VOLT  AC	12 VOLT DC
  Power Input	55 WATT	45 WATT
  Frequency	50 Hz	NA
  Current in Phase	0.25 A	3.75 A
  Speed @ Full	1400 rpm	1350 rpm
  Speed @ Slow	610 rpm	605 rpm
  Air Delivery	100 m3/min	85 m3/min
  Power Factor	0.97	NA
  Service Value	1.80 m3/min/W	1.85 m3/min/W
  Control of Fan	REMOTE CONTROL	REMOTE CONTROL
  Remote Type	RF REMOTE	RF REMOTE
  No. of Speeds	07	07
  Winding Material	Pure Copper	Pure Copper
  Timmer	1H-4H-8H	1H-4H-8H
