Chint NXB MCB
Price range: ₨ 900.00 through ₨ 6,500.00
Chint NXB-63C 1-Pole 10–63A miniature circuit breaker, 6kA breaking capacity, C-curve, DIN-rail mount.
Description
The Chint NXB-63C is a 1-pole miniature circuit breaker (MCB) rated 10–63A, offering reliable overload and short-circuit protection for residential and commercial distribution boards. Built to IEC 60898-1 with a 6kA breaking capacity and positive contact isolation.
- Brand: Chint
- Standard: IEC 60898-1
- Certification: CE
- Breaking capacity: 6kA
- Rated voltage: 230/400V AC, 50/60Hz
- Trip curves: B, C, D
- Rated impulse withstand (Uimp): 4kV
- Protection: overload & short circuit
- Mounting: 35mm DIN rail
Available amperages: 10,16,20,25,32,40,50,63A. Genuine Chint product supplied by Minhas Corporation with a 12-month warranty.
Additional information
| Series | NXB-63C, NXB-63H, NXB-125C |
|---|---|
| Poles | 1P, 2P, 3P, 4P |
| Current Range | NXB-63C 1P 10–63A, NXB-63C 1P 1–6A, NXB-63C 2P 10–63A, NXB-63C 2P 1–6A, NXB-63C 3P 10–40A, NXB-63C 3P 1–6A, NXB-63C 3P 50–63A, NXB-63C 4P 1–32A, NXB-63C 4P 40–63A, NXB-63H 1P 10–63A, NXB-63H 1P 1–6A, NXB-63H 2P 16–25A, NXB-63H 2P 1–10A, NXB-63H 2P 32–63A, NXB-63H 3P 1–32A, NXB-63H 3P 40–63A, NXB-63H 4P 1–4A, NXB-63H 4P 50–63A, NXB-63H 4P 6–40A, NXB-125C 4P 100–125A |
